XV U1000 R2V 3 Phase 16mm2 5 Core 5g35 Copper Conductor Insulated Electrical Power Cable Wire Prices

The specification parameters of the XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated Electrical Power Cable are the specific quantitative embodiment of its performance. Each parameter is precisely designed to meet the stringent requirements of low-voltage three-phase power distribution systems.

The conductor uses high-purity electrolytic copper of 5g35 specification with a purity of ≥99.95%. This purity level can minimize resistance loss during current transmission. The single wire diameter of the 16mm² main core is 0.25mm, and multiple single wires are stranded together through a bunch stranding process. The stranding pitch is controlled within 15-20 times the diameter of the single wire, which not only ensures the Flexibility of the conductor but also avoids looseness caused by overly loose stranding. At 20°C, the DC resistance of the main core is ≤1.15Ω/km, and the DC resistance of the auxiliary core (taking 4mm² as an example) is ≤4.61Ω/km, both far lower than the limits specified in the GB/T 5023 standard, ensuring efficient power transmission. The elongation at break of the conductor is ≥30%, which can withstand the tensile force during laying without breaking easily.

The rated voltage of this cable is U1000V, that is, the phase voltage is 1000V and the line voltage is 1732V, suitable for low-voltage power distribution systems. The thickness of the insulation layer is 0.8mm, and it can withstand a voltage of 3000V without breakdown in a 1-minute power frequency withstand voltage test. The insulation resistance is ≥100MΩ·km at 20°C, and the volume resistivity is ≥1×10¹³Ω·cm. The excellent insulation performance effectively prevents leakage and short-circuit accidents. In addition, the partial discharge amount of the cable is ≤10pC under 1.73U0 voltage, further ensuring the stability of the insulation.

The overall structural dimensions of the cable are precisely calculated to balance performance and installation convenience. The conductor diameter of the 16mm² main core is 5.1mm, and with the 0.8mm insulation layer, the Single Core diameter reaches 6.7mm. The cabling diameter after stranding 5 Cores is approximately 18mm, and after wrapping with a 0.6mm thick sheath, the final outer diameter of the cable is 19.2mm. The minimum bending radius is 6 times the outer diameter of the cable, which is 115.2mm. This parameter enables the cable to be flexibly laid in narrow spaces such as inside distribution boxes and wall trunking.

The long-term allowable operating temperature of the cable is 70°C. In case of a short circuit (duration ≤5s), the maximum temperature can reach 160°C, which can withstand instantaneous high-temperature impact without damaging the insulation layer. Its minimum laying temperature is -15°C, and when laid at this temperature, the cable sheath has no cracking, meeting the installation requirements in cold regions. At the same time, the cable performance remains stable in the temperature cycle test from -30°C to 70°C, with no obvious aging or cracking of the insulation layer and sheath.

The sheath of the cable has good mechanical strength, with a tensile strength of ≥12MPa and an elongation at break of ≥150%, which can withstand mechanical collisions and friction during laying and use. In the impact test, a 1kg weight is dropped freely from a height of 1m to impact the cable, and after the impact, the insulation performance and conductivity of the cable have no obvious changes. In the flexing test, after 20,000 bending cycles, the cable has no open circuit or short circuit, and the insulation resistance remains within the qualified range.

The XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated electrical power cable has a wide range of characteristic applications in various fields due to its unique performance advantages.

In industrial automation production lines, this cable is an ideal power connection line for motors, frequency converters, PLC and other equipment. In industrial environments, there are frequent mechanical vibrations and oil pollution. The flexible structure of the cable (R2V identifier) can adapt to the vibration of the equipment, reducing cable fatigue damage caused by vibration; the PVC Sheath has good oil resistance, which can resist the erosion of machine tool lubricating oil, hydraulic oil, etc., ensuring the long-term stable operation of the cable. For example, in the power supply system of welding robots in automobile manufacturing workshops, this cable can withstand the frequent movement of the robot arm and the high-temperature radiation of welding sparks.

Commercial buildings such as large shopping malls, office buildings, and hotels have dense electrical equipment and high requirements for the safety and reliability of power distribution. The 5-core design of the cable, with 3 main cores for transmitting three-phase current, 1 neutral wire and 1 Grounding Wire, meets the requirements of the three-phase five-wire power distribution system, eliminating the trouble of laying a separate grounding wire and reducing construction costs. In the power distribution of central air-conditioning systems and lighting systems in shopping malls, the flame retardant performance of the cable (oxygen index ≥30) can effectively delay the spread of fire, buying time for personnel evacuation. At the same time, its temperature resistance can adapt to the local high-temperature environment when air-conditioning equipment is running.

In municipal engineering, this cable is often used for power supply of street lamp systems, small pump stations, traffic signal lights and other facilities. Street lamp systems are usually installed outdoors, facing the test of natural environments such as wind, sun, and rain. The anti-ultraviolet additives in the cable sheath can resist the aging effect of ultraviolet rays, extending the service life of the cable; its weather resistance ensures stable performance under temperature changes in different seasons. In small pump stations, the cable can withstand humid environments and has certain corrosion resistance, which can cope with possible water vapor and slight chemical erosion in the pump station.

The data center computer room is an important place for electricity use, with extremely high requirements for the continuity and stability of power supply. The high-purity copper conductor of the cable can reduce power loss and ensure stable power supply for computer room equipment; its flexibility is convenient for laying in narrow spaces such as under the floor of the computer room and inside the cabinet, without affecting the overall layout of the computer room. At the same time, the flame retardant performance of the cable meets the fire safety requirements of the computer room, reducing the fire risk.

The material selection and style design of the XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated electrical power cable are important guarantees for its performance.

The conductor uses high-purity electrolytic copper, which is refined by electrolysis to remove impurities and has excellent conductivity. Compared with ordinary Copper Conductors, high-purity electrolytic copper has higher conductivity, which can reduce energy loss during current transmission. At the same time, its good ductility allows the Copper Wire to be drawn into fine single wires, facilitating the bunch stranding process and improving the flexibility of the conductor.

The insulation layer is made of polyvinyl chloride (PVC) material, which has good dielectric properties, chemical corrosion resistance and processing performance. The PVC Insulation layer is designed with a special formula, with a temperature resistance level of 70°C, and can maintain stable insulation performance within a certain temperature range. Compared with other Insulation Materials such as rubber, the PVC insulation layer has higher mechanical strength, is not easy to be damaged, and has a relatively low cost.

The sheath is also made of PVC material, but its formula is different from that of the insulation layer. The PVC of the sheath is added with flame retardants, anti-ultraviolet additives, plasticizers, etc. The addition of flame retardants makes the sheath have good flame retardant performance, which can inhibit combustion in case of fire; anti-ultraviolet additives improve the weather resistance of the sheath, extending the service life of the cable when used outdoors; plasticizers make the sheath have certain flexibility, facilitating the bending and laying of the cable.

The cable adopts a circular stranded style, with 5 cores stranded together according to a certain stranding pitch, and the outer part is wrapped with a sheath to form a circular cable structure. This style design makes the cable structure compact, occupies small space, and is convenient for pipe threading and trunking laying. In addition, according to the special needs of customers, sheath styles of different colors such as black and gray can also be provided to adapt to different installation environments and identification needs. For example, in the renovation project of ancient buildings, cables with sheath colors that coordinate with the architectural style can be provided to reduce the impact on the appearance of the building.

The production process of the XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated electrical power cable strictly follows national standards and industry norms, and adopts advanced production processes to ensure the stability of product quality.

First, the high-purity electrolytic copper rod is drawn into a single wire with a diameter of 0.25mm through a wire drawing machine. During the drawing process, a special lubricant is used to reduce wear on the surface of the copper wire. Then, multiple single wires are stranded through a bunch strander. During stranding, the number of single wires is determined according to the cross-sectional requirements of the main core and auxiliary core. During the stranding process, by precisely controlling the stranding speed and tension, it is ensured that the Stranded Conductor has a tight and round structure, avoiding defects such as looseness and broken wires. After stranding, the conductor is annealed by heating it to 300-400°C and then slowly cooling it to eliminate internal stress in the conductor and improve its flexibility and conductivity.

The insulation layer is formed by extrusion. The PVC Insulation Material is added to the hopper of the extruder, heated and melted, and then uniformly extruded and coated on the surface of the conductor through a mold. During the extrusion process, the extrusion temperature, speed and pressure are strictly controlled to ensure that the insulation layer has uniform thickness, smooth surface, and no defects such as bubbles and impurities. The thickness deviation of the insulation layer is controlled within ±0.1mm to ensure the stability of insulation performance. After extrusion, the Insulated Core is cooled to quickly solidify and shape the insulation layer.

3 main cores and 2 auxiliary cores are stranded into a cable through a cabling machine. During stranding, a untwisting device is used to avoid excessive twisting of the insulated core during stranding, which may cause damage. During the cabling process, non-hygroscopic filling materials are filled between the cores to make the cabled structure more round and stable, and also play a buffering and protective role. The filling material is polypropylene rope, which has good Chemical Resistance and mechanical strength.

After cabling, enter the sheath extrusion process. The PVC sheath material is added to the extruder, heated and melted, and then extruded and coated on the outside of the cabled core through a mold to form the sheath layer. The process parameter control of sheath extrusion is similar to that of insulation extrusion, ensuring that the sheath layer has uniform thickness, smooth surface, and is closely combined with the cable core. The thickness of the sheath layer is 0.6mm, and the deviation is controlled within ±0.1mm. After extrusion, the cable is cooled, pulled and taken up to form the finished cable.

The finished cable needs to undergo a series of strict inspections before leaving the factory. Inspection items include appearance inspection, dimension measurement, insulation resistance test, power frequency withstand voltage test, partial discharge test, mechanical performance test, etc. The appearance inspection mainly checks whether the sheath surface of the cable is smooth and free of damage; dimension measurement ensures that the outer diameter of the cable, the thickness of the insulation layer and the sheath meet the requirements; electrical performance test verifies the insulation performance and conductivity of the cable; mechanical performance test checks the tensile strength, elongation at break and other indicators of the cable. Only cables that pass all inspection items can be labeled with a certificate of conformity and leave the factory.

The packaging design of the XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated electrical power cable aims to protect the product, facilitate transportation and storage, and at the same time focus on environmental protection and clear identification.

Cables are usually packaged in reels, which are divided into wooden reels and steel reels. For cables with lengths of 100 meters and 200 meters, wooden reels are generally used. The wooden reels are made of high-quality pine wood, which has certain strength and toughness and can bear the weight of the cable. The diameter of the reel is 600mm, the width is 200mm, the thickness of the side plate is 20mm, and the hub diameter is 200mm, ensuring that the reel is not easy to deform during transportation and storage. For long-length cables with lengths of 500 meters and 1000 meters, steel reels are used. The steel reels are welded from steel plates, and the surface is galvanized, which has good rust resistance and can be reused. The diameter of the steel reel is 800-1200mm, and the width is determined according to the length of the cable, which can meet the packaging needs of long-length cables.

Before packaging, the cable needs to be neatly wound on the reel. During the winding process, the tension is controlled to avoid loosening or excessive stretching of the cable. After winding, the outer layer of the cable is wrapped with a layer of plastic film to prevent the cable from being contaminated with dust and moisture during transportation. Then, the cable is fixed on the reel with steel strips. The tightening force of the steel strips is moderate, which should ensure that the cable does not loosen and not excessively squeeze the cable to cause deformation. Iron rings for easy handling are installed on both sides of the reel, and the strength of the iron rings can bear the total weight of the reel and the cable.

Clear marks are printed on the side plates of the reel, including product model, specification (3-phase 16mm² 5-core), length, rated voltage, production batch number, production date, implementation standard, manufacturer's name, address and contact information, etc. These marks are convenient for users to identify the basic information of the product and for the manufacturer to carry out quality traceability. At the same time, a product certificate is attached to the reel, which indicates the inspection results of the product and the inspector's number.

In response to environmental protection requirements, packaging materials are strive to use recyclable and biodegradable materials. The wooden reels are made from wood sourced from sustainably managed forests, meeting FSC certification standards; the plastic film is made from biodegradable PE material, which can gradually decompose in the natural environment, reducing pollution; and the steel straps used for packaging are recyclable, helping to reduce resource waste.

Appropriate measures need to be taken during the transportation of the XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated electrical power cable to ensure that the product is not damaged during transportation.

According to the transportation distance and customer needs, road transportation, railway transportation, waterway transportation and other methods can be selected. Road transportation is suitable for short-distance transportation, using truck transportation. The truck compartment needs to be flat, clean and free of sharp objects. During transportation, the reels are placed horizontally in the compartment, and wooden blocks are placed between the reels to prevent mutual collision. For steel reels, steel wire ropes can be used to fix them on the compartment to ensure that the reels do not shake during transportation. Railway transportation is suitable for medium and long-distance transportation. The reels are placed on the flat car of the railway freight car, and the same fixing method is adopted to ensure transportation safety. Waterway transportation is suitable for long-distance and export transportation. The reels are loaded into containers. The containers should be kept dry and ventilated, and buffer materials are filled between the reels to prevent damage to the cable caused by bumps during transportation.

During transportation, the reel should be prevented from being inverted or tilted at an excessive angle (not exceeding 15°) to prevent the cable from slipping off the reel. When transporting in rainy days, the cable needs to be covered against rain, and the reel is wrapped tightly with waterproof canvas to prevent rainwater from entering the cable and affecting the insulation performance. The driving speed of the transport vehicle should be moderate, avoiding sudden braking and sharp turns to reduce the vibration and impact of the reel. When loading and unloading cable reels, special lifting equipment such as forklifts and cranes should be used. It is strictly forbidden to manually drag the reels to avoid damaging the reels and cables. When lifting, the lifting tool should be hung on the special lifting ring of the reel, and not on the cable to avoid

ctor.

The insulation layer is made of polyvinyl chloride (PVC) material, which has good dielectric properties, chemical resistance, and processability. The PVC insulation layer is designed with a special formula and has a temperature resistance level of 70°C, which can maintain stable insulation performance within a certain temperature range. Compared with other insulation materials such as rubber, the PVC insulation layer has higher mechanical strength, is not easy to be damaged, and has a relatively low cost.

The sheath is also made of PVC material, but its formula is different from that of the insulation layer. The PVC of the sheath is added with flame retardants, anti-ultraviolet additives, plasticizers, etc. The addition of flame retardants makes the sheath have good flame retardant performance, which can inhibit combustion in case of fire; anti-ultraviolet additives improve the weather resistance of the sheath, extending the service life of the cable when used outdoors; plasticizers make the sheath have certain flexibility, facilitating the bending and laying of the cable.

The cable adopts a circular stranded style. The 5 cores are stranded together according to a certain stranding pitch, and the outer part is wrapped with a sheath to form a circular cable structure. This style design makes the cable structure compact, occupies small space, and is convenient for threading and trunking laying. In addition, according to the special needs of customers, sheaths of different colors such as black and gray can also be provided to adapt to different installation environments and identification needs. For example, in the renovation project of ancient buildings, cables with sheaths in colors that coordinate with the architectural style can be provided to reduce the impact on the appearance of the building.

The production process of the XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated electrical power cable strictly follows national standards and industry norms, and adopts advanced production technology to ensure the stability of product quality.

First, high-purity electrolytic copper rods are drawn into single wires with a diameter of 0.25mm through a wire drawing machine. A special lubricant is used during the wire drawing process to reduce wear on the surface of the copper wires. Then, multiple single wires are stranded together through a bunch strander. During stranding, the number of single wires is determined according to the cross-sectional requirements of the main core and the auxiliary core. During the stranding process, the stranding speed and tension are precisely controlled to ensure that the stranded conductor has a compact and round structure, avoiding defects such as looseness and broken wires. After stranding, the conductor is annealed. The conductor is heated to 300-400°C and then slowly cooled to eliminate internal stress in the conductor and improve the flexibility and conductivity of the conductor.

The insulation layer is formed by extrusion molding. PVC insulation material is added to the hopper of the extruder, heated and melted, and then uniformly extruded and coated on the surface of the conductor through a mold. During the extrusion process, the extrusion temperature, speed, and pressure are strictly controlled to ensure that the insulation layer has uniform thickness, a smooth surface, and no defects such as bubbles and impurities. The thickness deviation of the insulation layer is controlled within ±0.1mm to ensure the stability of insulation performance. After extrusion, the Insulated Wire core is cooled to quickly solidify and shape the insulation layer.

3 main cores and 2 auxiliary cores are stranded into a cable through a cabling machine. A untwisting device is used during cabling to avoid excessive twisting of the insulated wire core during cabling, which may cause damage. During cabling, non-hygroscopic filling material is filled between the cores to make the cabled structure more round and stable, and at the same time play a buffering and protective role. The filling material is polypropylene rope, which has good chemical resistance and mechanical strength.

After cabling, the cable enters the sheath extrusion process. PVC sheath material is added to the extruder, heated and melted, and then extruded and coated on the outside of the cabled core through a mold to form a sheath. The process parameter control of sheath extrusion is similar to that of insulation extrusion, ensuring that the sheath has uniform thickness, a smooth surface, and is tightly combined with the cable core. The thickness of the sheath is 0.6mm, and the deviation is controlled within ±0.1mm. After extrusion, the cable is cooled, pulled, and taken up to form a finished cable.

Finished cables need to undergo a series of strict inspections before leaving the factory. Inspection items include appearance inspection, size measurement, insulation resistance test, power frequency withstand voltage test, partial discharge test, mechanical performance test, etc. Appearance inspection mainly checks whether the surface of the cable sheath is smooth and free of damage; size measurement ensures that the outer diameter of the cable, the thickness of the insulation layer and the sheath meet the requirements; electrical performance tests verify the insulation performance and conductivity of the cable; mechanical performance tests check indicators such as tensile strength and elongation at break of the cable. Only cables that pass all inspection items can be labeled with a certificate and leave the factory.

The packaging design of the XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated electrical power cable aims to protect the product, facilitate transportation and storage, and at the same time pay attention to environmental protection and clear identification.

Cables are usually packaged on reels, which are divided into wooden reels and steel reels. For cables with lengths of 100 meters and 200 meters, wooden reels are generally used. The wooden reels are made of high-quality pine, which has certain strength and toughness and can bear the weight of the cable. The diameter of the reel is 600mm, the width is 200mm, the thickness of the side plate is 20mm, and the diameter of the hub is 200mm, ensuring that the reel is not easy to deform during transportation and storage. For long-length cables with lengths of 500 meters and 1000 meters, steel reels are used. The steel reels are made of steel plates by welding, and the surface is galvanized to have good rust resistance and can be reused. The diameter of the steel reel is 800-1200mm, and the width is determined according to the length of the cable, which can meet the packaging needs of long-length cables.

Before packaging, the cable needs to be neatly wound on the reel. During the winding process, the tension is controlled to avoid loosening or excessive stretching of the cable. After winding, the outer layer of the cable is wrapped with a layer of plastic film to prevent the cable from being contaminated with dust and moisture during transportation. Then, the cable is fixed on the reel with steel strips. The tightening force of the steel strips is moderate, which should ensure that the cable does not loosen and cannot excessively squeeze the cable to cause deformation. Iron rings for easy handling are installed on both sides of the reel, and the strength of the iron rings can bear the total weight of the reel and the cable.

Clear marks are printed on the side plates of the reel, including product model, specification (3-phase 16mm² 5-core), length, rated voltage, production batch number, production date, implementation standard, manufacturer name, address, contact information, etc. These marks are convenient for users to identify the basic information of the product and for the manufacturer to carry out quality traceability. At the same time, a product certificate is attached to the reel, which indicates the test results of the product and the inspector number.

In response to environmental protection requirements, packaging materials try to use recyclable and degradable materials. The wood used for wooden reels comes from sustainable forests and meets the FSC certification standards; the plastic film is made of degradable PE material, which can be gradually decomposed in the natural environment, reducing environmental pollution; the steel strips used for packaging can be recycled and reused, reducing resource waste.

Appropriate measures need to be taken during the transportation of the XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated electrical power cable to ensure that the product is not damaged during transportation.

According to the transportation distance and customer needs, road transportation, railway transportation, waterway transportation and other methods can be selected. Road transportation is suitable for short-distance transportation. Trucks are used for transportation. The truck compartment needs to be flat and clean, with no sharp objects. During transportation, the reels are placed horizontally in the compartment, and wooden blocks are used to separate the reels to prevent mutual collision. For steel reels, wire ropes can be used to fix them on the compartment to ensure that the reels do not shake during transportation. Railway transportation is suitable for medium and long-distance transportation. The reels are placed on the flat car of the railway freight car, and the same fixing method is adopted to ensure transportation safety. Waterway transportation is suitable for long-distance and export transportation. The reels are loaded into containers. The containers should be kept dry and ventilated, and buffer materials are filled between the reels to prevent cable damage caused by 颠簸 during transportation.

During transportation, the reel should not be inverted or tilted at an excessive angle (not exceeding 15°) to prevent the cable from slipping off the reel. When transporting in rainy days, the cable needs to be covered with rainproof covers, and the reel should be wrapped tightly with waterproof canvas to prevent rainwater from entering the cable and affecting the insulation performance. The driving speed of the transport vehicle should be moderate, avoiding sudden braking and sharp turns, to reduce the vibration and impact of the reel. When loading and unloading cable reels, special lifting equipment such as forklifts and cranes should be used. It is strictly forbidden to manually drag the reels to avoid damaging the reels and cables. When lifting, the spreader should be hung on the special lifting rings of the reel, and it is not allowed to hang on the cable to cause damage to the cable due to force.

For important transportation orders, GPS positioning systems can be used to monitor the transport vehicles in real time, master the driving route, speed and position information of the vehicles, and timely discover and handle abnormal situations during transportation. At the same time, the transport driver should regularly check the packaging of the cable and deal with problems in time.

The delivery process of the XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated electrical power cable is standardized and orderly to ensure that the product is delivered to customers in a timely and accurate manner.

After receiving the customer's order, the sales staff checks the product model, specification, quantity and other information with the warehouse management personnel to confirm the inventory status. If the inventory is sufficient, the warehouse management personnel prepares the products according to the order requirements, inspects the appearance and marks of the products, and ensures that the products meet the order requirements. If the inventory is insufficient, production is arranged in a timely manner. After production, the products are inspected and stored in the warehouse for delivery.

The warehouse management personnel transfers the products from the warehouse according to the delivery note and hands them over to the logistics department for transportation arrangement. The logistics department selects appropriate transport vehicles and drivers according to the transportation method and destination, and goes through relevant transportation procedures. Before delivery, the logistics personnel checks the product information together with the warehouse management personnel, and signs on the delivery note after confirmation. Then, the products are loaded onto the transport vehicle and fixed and covered according to the transportation requirements. After delivery, the logistics department timely feeds back the delivery information (such as the license plate number of the transport vehicle, the driver's contact information, the estimated arrival time, etc.) to the customer so that the customer can prepare for receipt.

For customers' emergency orders, the company provides emergency delivery services. Production and inspection are given priority to shorten the production cycle. At the same time, the fastest transportation method, such as air transportation or expedited road transportation, is selected to ensure that the products are delivered to customers in the shortest possible time. The emergency delivery service requires customers to pay the corresponding expedited fee, and the specific fee is determined according to the transportation distance and the quantity of products.

To allow customers to fully understand the performance and quality of the XV U1000 R2V 3-Phase 16mm² 5-Core 5g35 copper conductor insulated electrical power cable before purchasing, the company provides sample services.

The specifications of the samples are the same as those of the bulk products, and the length is usually 1-5 meters, which can be selected by customers according to their needs. For customers with special testing needs, longer samples, such as 10 meters, can be provided to meet the requirements of customers for various performance tests. The quantity of samples is generally 1-2 sections. If more quantities are needed, customers can negotiate with the sales staff.

Customers can apply for samples through the company's official website, telephone, email, etc. When applying, it is necessary to provide information such as customer name, contact information, company address, and the model and specification of the required samples. After receiving the sample application, the sales staff will contact the customer within 24 hours to confirm the sample requirements and related details. For regular customers, samples are provided free of charge (only freight is borne); for new customers, a deposit may be charged, which will be refunded after bulk procurement. Samples are usually delivered by express, and the delivery time is 3-5 days nationwide.

The company provides sample test reports, including key indicators such as conductor resistance, insulation thickness, and withstand voltage performance, to help customers quickly understand product performance. If customers need to conduct third-party testing, the company can assist in contacting authoritative testing institutions (such as China Electrical Equipment Testing Institute) and provide necessary technical parameters.

The company provides a complete after-sales service system to solve customers' problems in installation, use and maintenance, and ensure the stable operation of the cable.

The warranty period of the XV U1000 R2V Cable is 5 years from the date of delivery. During the warranty period, if the cable has quality problems (such as insulation breakdown, sheath cracking) due to manufacturing defects, the manufacturer provides free replacement or repair services; for damage caused by improper installation or man-made factors, paid maintenance services are provided.

A professional technical team is set up to provide 7×24-hour technical consultation services, answering customers' questions about installation specifications, laying methods, and fault diagnosis. For large projects, on-site technical guidance can be arranged, including cable laying supervision, joint processing demonstration, etc., to ensure that the installation quality meets the design requirements.

In case of cable failure during use, the manufacturer responds within 2 hours after receiving the report, formulates a solution within 24 hours, and dispatches technicians to the site for handling if necessary. For urgent faults affecting power supply, emergency repair teams are arranged to rush to the site for repair, minimizing the downtime loss of customers.

The manufacturer establishes a customer feedback mechanism, collects opinions and suggestions on product performance and service through regular return visits and questionnaires, and uses them as an important basis for product improvement and service optimization. For reasonable suggestions adopted, customers are given certain rewards (such as discounts on the next order).
